Description
Pitch:5.08mm
Poles:2P
Screw:M2.5 Steel Zinc plated
Pin header: Brass, Tin plated
Terminal wiring size: 14 – 22 AWG
Housing: PBT, UL94V-0
Rated current: 16A
Withstanding voltage: 250VAC
Weight | 0.010 kg |
---|---|
Pitch | 5.08mm |
Poles | 2P |
Screw | M2.5 Steel Zinc plated |
Pin header | Brass, Tin plated |
Terminal wiring size | 14 – 22 AWG |
Housing | PBT, UL94V-0 |
Rated current | 16A |
Withstanding voltage | 250VAC |
Description
Pitch:5.08mm
Poles:2P
Screw:M2.5 Steel Zinc plated
Pin header: Brass, Tin plated
Terminal wiring size: 14 – 22 AWG
Housing: PBT, UL94V-0
Rated current: 16A
Withstanding voltage: 250VAC
